Electric Bolt Lock with Key Cylinder– Fail Secure (Ultra Narrow)
Features
- Ultra Thin & Narrow innovative design, Smart / Simple / Elegant
- Door position status monitor output contact
- Adjustable door lock delay timer
- Release door when failure or power off
- For aluminum door, steel door, brass door, wooden door
Specification
| Model No. | DA-66SL | |
|---|---|---|
| Type | Fail secure | |
| Voltage / Current | DC12V(Standby:230mA , Working:1000mA) | |
| Time Delay | 10 Sec. / 5 Sec. / 4 Sec. | |
| LED indicator | YES | |
| Door position sensor | YES | |
| Dimension (LxWxD)mm | Faceplate | 243x25.4x3 |
| Lock | 187x23x33 | |
| Net Weight (g) | 350g±1% | |
| Bracket | SL-70E: Thumbturn Euro Cylinder lock (70mm), Door thickness 44~49mm) | |
Accessories
SL-70E: Euro-profile Thumb Turn Cylinder(Length70mm / Door thickness 44~49mm)
Dimension: mm
We reserve the right to change the specification without prior notice or obligation!
