UHF 868MHz, 928MHz Long Range RFID Reader And Writer

PK-UHF201 Long Range UHF RFID Reader And Writer

Model number： PK-UHF201

Inquiry

Quantity

Product Description

PK-UHF201 is one of high-performance long range UHF reader, combining proprietary signal processing algorithms and efficient, with a high recognition rate processing performance and fast read and write, can be widely used in logistics, parking systems, access control systems, security systems and production process control, and other radio frequency identification (RFID) systems.

Features

Protocol comply with UHF EPC Gen2(ISO18000-6C), ISO 18000-6B standard.
Working frequency 902～928MHz(PK-UHF201U) / 865～868MHz(PK-UHF201E)
Support adjustable frequency range (FHSS) or fixed specific working frequency.
Power output 0-30dBm (adjustable)
Built-in 12dBi linear polarized antenna as choice；Reading range 25M＊.
Support operation Modes as Answer, Active, Trigger mode.
Low power design, Input Power: DC +9V.
Support RS-232, RS-485, Wiegand 26/34 Interface. Optional TCP/IP, POE, Wifi.
* Effective distance depends on antenna, tag and environment.

Specifications

Dimension	445(L) x 445(W) x 55(H)mm
Protocol	ISO18000-6B, EPC Class 1 Gen2(ISO18000-6C)
Protection Grade	IP54
Work Frequency	Standard ISM 865-868MHz(PK-UHF201E), 902~928MHz(PK-UHF201U)
Frequency Hopping	FHSS
Power Output	0-30dBm(adjustable)
Antenna	Built-in 12dBi linear polarized antenna (optional for circular antenna)
Interface	RS232, RS485, wiegand 26/34(TCP/IP,Wifi can be customized）
Operating Mode	Answer,Active,Trigger
Read Range	3~25m
Write Range	0~6m
Reading Clue	Buzzer
Input Power	100-240V,DC+9V (Power Adapter)
Power Consumption	1W
Operation Temp	-25°C~+60°C
Storage Temp	-25°C~+80°C
Humidity	80%
Regulatory	Compliant with CE,FCC
Additional services	Provide Demonstration software and SDK for further development.
