Access Control/Time & Attendance / Lift Access Control Software
Access Control Software Features
- Drop-down menu, easy for operation.
- Can control multi readers on line at the same time, and show user’s photo、name、time zone data、in/out records.
- Database is Microsoft Access format; it can transfer data to TXT form.
- Multitasking environment, can operate other software while running this software, and can monitor host monitoring of files editing
- and processing.
- Can choose COM PORT(COM1~COM4) or TCP/IP as transmission.
- Offer 15 kinds of common reader setting, administrators can easily to manage readers through PC.
- Timing can be set as automatically upload from computer time to correct card reader, so always keep correct time for card reader.
- Responsive reader provides the reader parameter query function.
- Provide export/ import database functionality, when the software version updates, no need to re-establish basic information.
- System program with database editing, storage and loaded reader functions; Can be used have records while database editing.
- Provide database management functions, delete、export / import, database compression function.
- System program with all of door zone, date, hour / minute, multi conditions query and abnormal query, print out the latest.
- information and provides export.
- Text files and Excel files functions.
- Can import/ export staff access records, staff data, staff personnel access permission data, and supports Excel file format.
- Can adjust field of access records as demand when printed.
- System program can automatic detect status of the controllers and card readers to know if it on line.
- Reader can be selected operation modes: (1) Card + PIN (2) Card only. (3) Card or Pin.
- Can accommodate maximum of 30,000 different identification number (ID) and password (PIN).
- Can be set to different time zones, to allow only specific users to access.
- Support multiple operation modes (EX: Card or Card+ Password) and access data receiving schedule (for specific model only).
- Remote door open by computer.
- System supports real-time reporting, the latest 30 numbers in-out record will display on computer screen.
- Support access report export to text file.
- Support text format adjustment to be used on personnel or other system.
- Provide manual import for original text file.
- Support limited period setting for legal card (for specific model).
- Support Door access controller and Lift access controller.
- Support lift door open at specific floor.
- Support multiple models.
- Support Time group settings, no need to set up personal access authority one by one.
- Need user password to enter main screen, administrator can modify user password and user operation authority.
- Provide operation user manual.
- Need user password to enter main screen, administrator can modify user operation authority. Support 27 function.
- settings to meet different requirements.
- Support lift group settings, door access controller and lift access controller are supported.
- Support specific floor relay activation.
- Support group authority settings, no need to set up personal access authority one by one.
- Support automatically receiving data without log-in.
- Support automatic data receiving schedule.
- Support background image change.
- Support 2750/3750/3760/6750/6750V/PP85/1074/5707T/370/377
- PST-ADV-E-ELE access control software supports above functions.
- PST-ADV-E-ELE access control software supports database editing with multiple languages (but some languages are not supported due to database or software limited).
- Above functions are supported with specific models, please check models in advance.
